Jinan CNC Controlled Automation Angle Steel Marking, Punching And Cutting Processing Line Model JX125 For Iron Tower

Category:ANGLE PROCESS LINE

Product specifications:
Jinan FAST CNC Machinery Co., Ltd specializes in CNC ...

Angle steel line, Steel angle fabrication, Angle processing line, Angle Punching Marking processing, Angle processing Punching cutting machine, CNC angle line solution

  • CNC Controlled Automation Angle Steel Marking, Punching And Cutting Processing Line Model JX125

    Jinan CNC Controlled Automation Angle Steel Marking, Punching And Cutting Processing Line Model JX125 For Iron Tower

    APPLICATION

    This machine is mainly used for angle steel marking, punching, and shearing special machine for fully automated production. It is widely used in power towers, communication towers, three-dimensional garages, steel structure buildings and other industries.



    FEATURES

    • Integrated machine with mechanical, electrical and hydraulic elements;
    • There are three sets of punching dies on the two wings of the angle steel. All the holes on the angle steel can be processed in one pass;
    • Single-edged cutting saves raw materials and cuts the surface neatly;
    • The quasi-distance can be set arbitrarily, and the number of punching rows is not limited;
    • The marking unit adopts a closed bed structure, which has good rigidity. Four groups of selected programming on the upper marking box. The marking distance can be set at will;
    • The hydraulic system mainly completes punching, cutting, marking, pressing and marking box interchanging;
    • The control system is composed of a host computer, servo motor, PLC, external detection sensor, etc.;
    • The CNC feeding trolley is driven by a servo motor with high positioning accuracy. The structure adopts a linear guide rail and hard racks, which has a long life and a more stable performance;
    • There are various input methods, such as keyboard and mouse input, USB interface input, network interface input.The data generated directly by the 3D or 2D software.
    • The main electrical control components and hydraulic and pneumatic components are imported accessories;
    • Providing G-code software program that can directly convert CAD graphics into executable machine ;
    • Graph display of processed parts;
    • With fault self-diagnosis function.


    TECHNICAL DATA

    Item Name Unit Specifications
    1 Angle steel placement type

    V placement

    (corner down)

    2 Processing angle steel range mm 45x45x4- 125x125x12
    3 Maximum length of blank mm 12000
    4 Processing criteria mm 25-100
    5 Feeding speed m/min Max.60
    6 Control method   CNC
    7 Data input method   Keyboard, mouse, USB
    8 File format   DWG,DXF
    9 Number of CNC axes   3
    10 Electricity environment   3Ph,380V,50Hz,0-45oC
    11 Dimensions m 23×6.5×2.5


    FAQ

    · Are you a Manufacturer or a Trading company?

    Manufacturer + trading company integration),focusing on CNC machines for 18 years. Integration with Design,Machining and Assembly.

    Exporting to Russia,USA,Australia,VietnamBrazil,Ethiopia,TunisiaBulgaria,India,Indonesia,Jordan,Pakistan,etc

    · Do you have stock product ready to delivery

    In order to satisfy with customer for fast delivery, we have certain amount of machines in stock.

    · After an order is placed,when to delivery

    General 30 working days. It depends on specific items and item quantities.

    Please check with sale manager for exact delivery time.

    · What is the Warranty with After-sale Services?

    12 months warranty after delivery. Engineers will provide training program for operation and trouble shouting during installation. They visit customers regularly for service. All questions will be answered within 3 hours and 90% problem will be solved within 24 hours.

    After the warranty, the professional after-sale service team will provide perfect technical support and help customer solve problems encountered.

    · What about the product quality

    Each machine must be carried out quality examination and test when shipping and delivery goods.
